Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants

10pieces
MOQ
$98.00/pieces 1-9 pieces
Price
Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants
Features Gallery Product Description Request A Quote
Features
Specifications
Application: General
Port Size: DN300, 12" (DN300)
Power: Pneumatic
Temperature Of Media: Low Temperature, Medium Temperature
Structure: BUTTERFLY
Customized Support: OEM, ODM
Product Name: Manual Butterfly Valves
Body Material: Aluminum Alloy
Valve Disc: Ductile Iron
Drive Mode: Manual Drive
Connection: Flange Ends
Basic Infomation
Place of Origin: China
Brand Name: Mandiwi, WAM, Sicoma, customized
Model Number: MV2FS300GBN-CM
Payment & Shipping Terms
Packaging Details: 1pcs per corrugated carton, with foam protection
Delivery Time: 10-15 working days
Payment Terms: T/T, LC, Trade assurance Order, Western Union
Product Description





Product Description:



MDW manual operated butterfly valves

butterfly valves, double flange ends.

with handle lever. manual operated



Fixed under hoppers, silos, bins to control the flow of powdery and granular materials.

Easy to hanle, light weight.

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 0

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 1



Features:



1. Small and light , and easy installation and maintenance. It can be mounted wherever needed.

2. Compact structure, 90 degree fast switch.

3. Minimized operating torque, energy saving.

4. Flow curve tending to straight line. Excellent regulation performance.

5. Long service life Standing the test of tens of thousands opening/closing operations.

6. Bubbles-tight sealing with no leakage under the pressure test.

Wide selection of materials, applicable for various medium.



Plate

Disc in cast iron, or stainless steel. Adopt frame structure, high strength, good toughness, large flow area, small flow resistance



Seal

Soft sealing material, reliable sealing performance.



Valve body

High-pressure aluminum alloy die-cast bodies



Valve Stem

High Strength stem provides maximum strength for high torque applications.



Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 2

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 3

Packing & Delivery:

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 4

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 5

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 6





Company Introduction:



Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 7

Hunan Jiancheng Technology Co., Ltd. is an industry and trade integrated enterprise focusing on the R&D and manufacturing of Mechanical Components and Spares for Batching Plants and crushers.



Mandiwi (MDW), as an independent brand under Jiancheng Technology, has established an product R&D laborary based on studying big data on the actual working conditions of global concrete machinery and equipment, now providing more cost-effective, high-quality and longer service life products and spares, including Valves, Level Monitoring Components, Vibrators, Dust Filters and Flow Aids, Screw Conveyors and Parts, Concrete Mixers, etc.



After years of development, the MDW has built in-depth cooperation relationships with many internationally renowned enterprises such as Sany, Zoomlion, CRCC, Sunward, CSCEC, Shantui, Xinzhu, etc. And our products have exported to Europe, North America, South Asia, West Asia, Middle East, Africa and other countries and regions.

‘Focus, Simplicity, Efficiency and Reliability ’ are the design concepts that the MDW brand has always adhered to since its establishment.



‘Escorting the operation of the mixing station and creating maximum value for customers’ is the company mission pursued by all MDW staffs.



Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 8



Our office:

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 9

Our meetings Room:

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 10

Certifications:

ISO9001, ISO14001,CE, ...

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 11

Why Choose Us

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 12



Professional Teams;

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 13



5000square meter central warehouse

Structure BUTTERFLY 12in Manual Operated Powdery Butterfly Valve for Batching Plants 14
